Up next Fuel Filter Fix: Rebuilding A Leaky Duramax Head Published on April 21, 2016 Author Trent Riddle Tags 6.7l, 6.7L power stroke, Contamination Repair, Cummins, def contamination, DEF tank, diesel engine, diesel trucks, diesel world, Dodge, Dodge Diesel, Dodge Ram, ECU, Engine Maintenance, Engine Modifications, ford, Ford Diesel, Fuel Injection, Fuel Nozzle, Fuel Pumps, Fuel Rails, fuel system, general motors, GM, gm diesel, power stroke, Pressure Pump, Ram, Tech, Share article Facebook 0 Twitter 0 Mail 0 Diesel Exhaust Fluid (DEF): The Downsides of Misuse Back in the September 2014 issue of Diesel World we talked about diesel exhaust fluid (DEF), which is used as an exhaust treatment in modern diesel emissions systems to reduce the levels of nitrogen oxide (NOx) in the exhaust. Used properly, DEF is a good thing—but used improperly, it can cause serious (and seriously expensive) problems. A quick Web search will turn up numerous (and, to some, humorous) tales of folks putting DEF into their non-DEF trucks and cars. Typically this happens when someone pours DEF into the fuel tank on older diesel rigs. We’ve heard stories of vehicle owners who think that if DEF is so good for new diesel trucks, it should be good for their older diesel as well. Also to blame: well-meaning service station attendants, techs at non-diesel shops, and even owners of gas rigs hoping to reap the benefit of increased fuel economy. The truth, of course, is that DEF is only useful in a rig with a DEF system, which consists of a separate tank, filler cap and fluid lines as well as a specialized exhaust system. But even trucks that require DEF are not immune from potential problems: Ford and Ram put their DEF filler necks inside the fuel filler door, right next to the fuel filler. A diesel fuel nozzle won’t fit into the DEF filler, but there’s nothing to stop someone from pouring DEF into the fuel tank. (This, by the way, is why we prefer GM’s setup, which puts the DEF tank under the hood.) Someone who’s used to the routine of opening the fuel filler door and removing the fuel cap could easily have a lapse of concentration and put DEF in the fuel tank—a simple mistake that could send a truck to the scrapyard.Subscribe Our Weekly Newsletter 1. To service the entire fuel system on a Ford, it’s much easier to raise the body to gain access to the all the fuel systems parts. This is essentially how Ford builds the truck; the frame assembly is mated to the body assembly on the line. Removing the body is actually a rather simple operation, provided you have a lift. [divider]WHAT IS DEF?[/divider] Diesel exhaust fluid (DEF) consists of 32.5 percent high-purity synthetic urea and 67.5 percent deionized water. DEF is slightly heavier than water at 9.08 lbs. per gallon (versus 8.34). Despite marketing names such as AdBlue and Blue DEF, it’s a clear liquid with a slight smell of ammonia. DEF has a freezing point of 12 degrees Fahrenheit, but since both urea and water freeze and thaw at the same rate, it’s okay to use if frozen and thawed. Most trucks have a DEF heating system to keep the truck running in extremely cold weather. 2. DEF contamination requires removing the entire fuel system from the main tank to the injectors. Here you see the tank, primary fuel pump and duel tank switching valve. Plastic fuel tanks can usually be flushed several times and reused. The rest of the system must be replaced. 3. The fuel cooler is just forward of the pump and switching valve on the driver’s side of the frame. It must be replaced as the cross passages are a perfect place for DEF crystals to hide. [divider]WHAT TO DO IF YOU GET DEF IN YOUR FUEL[/divider] If you suspect you have DEF in your diesel’s fuel system, do not drive the vehicle and do not attempt to start the engine. Don’t even turn the key on, as this will energize the fuel system and could pump DEF-contaminated fuel into the rest of the fuel system. If the error is caught before the key is turned, the fix may be as simple as dropping the fuel tank and flushing it out. Have the vehicle towed or flat-bedded to a repair facility, and if you need to unlock the steering column, be sure to disconnect the batteries before turning the key in the ignition. Make sure get your vehicle repaired right away, as DEF is corrosive and letting it sit in the fuel system can cause further damage. 4. Tech Rody Henriquez begins the DEF contamination repair by stripping off the engine components that ride over the fuel system. Here the plastic intake is coming off. 5. After the plastic is off, Henriquez removes the aluminum manifold. [divider]SYMPTOMS OF FUEL CONTAMINATION[/divider] Ford lists several symptoms of fuel contamination: -Engine cranks but does not start -Long crank/hard starting -Engine runs rough -Low power -Engine knocking -Exhaust smoke -Fuel rail pressure (FRP) slow to build These symptoms, among others, are indicators of some sort of contamination in the fuel system. not necessarily DEF—but of all the possible types of liquid contamination, DEF is by far the worst. According to Ford, the most common sources of contaminated fuel are auxiliary vehicle-mounted tanks; local storage tanks; infrequently used fuel sources; and refueling errors (i.e. DEF or gasoline poured into the fuel tank). 6. The entire fuel system is stripped out. Here the injector feed lines are being removed. 7. The aluminum fuel rails on both sides must be discarded. If recycled, they may come back as a new F-150 body part. 8. All the injectors must be removed. Some say that they can be cleaned and reused; while this may be true for other service issues such as water contamination, the nature of DEF (corrosive and abrasive) means the injectors must be replaced. And no, we’re not being overly dramatic. DEF is corrosive and, as you are about to see, causes severe damage to the fuel system. Early symptoms include hard starting, rough idle and smoking exhaust, and a DEF-contaminated engine may not start at all. The recommend repair is to replace the entire fuel system, from tank to injectors. We’ve seen reports of Ford dealerships quoting between $12,000 and $20,000 to replace a DEF-contaminated fuel system. As these trucks age, the cost of DEF repair could easily be more than the value of the vehicle. We followed the repair of a DEF-contaminated 6.7-liter Ford Power Stroke at Domestic Diesel in Chino, California. Shop owner John Ferguson is a Ford-certified mechanic and spent years with Ford before opening his own shop, which is also a Bosch Authorized Diesel Vehicle Diagnostic Center and has access to Ford and Bosch OEM replacement parts. While Domestic’s quote was lower than the dealership, this was still an extensive and expensive repair, and they were kind enough to let us document both the damage and the fix as diesel tech Rody Henriquez worked on a DEF-contaminated Ford. DW 9. The fuel filters must be replaced along with their filter housings. The small cost of a new housing pales in comparison to having to replace the entire fuel system a second time. Don’t forget the water separator. 10. Here you see a fuel filter that’s encrusted with urea crystals from DEF. This is a sure sign of DEF contamination in the fuel. 11. Urea crystals form as the water in DEF evaporates. Seen here is a DEF spill. These crystals are death to your high-pressure injectors—they have the same effect as running sand through the fuel system. 12. Here you see the entirety of the engine-mounted fuel system from our 6.7L Power Stroke. All of the injectors are being replaced, along with the high-pressure pump, filter and all fuel lines. 13A/13B. The high-pressure fuel pump is timed with the cam. It’s essential that this pump be installed properly or truck won’t run. The two marks on the cam and drive gear must be in the proper position before installing your new pump. 14. The new injectors are installed and torque to spec. Once the rest of the fuel system is reassembled, the truck is ready to roll. 15A/15B. Each individual injector on the 6.7L Ford Power Stroke has its own ID code. When the trucks roll out of the factory, these numbers are printed on the valve cover. Each new injector must have its code entered into the engine ECU. 16. Avoid DEF contamination—remember that DEF goes in the smaller filler hole with the (usually) blue cap marked DEF, not directly into the fuel tank. Most auto parts stores carry 1-gallon bottles and 2.5-gallon boxes of DEF. The 2.5-gallon boxes have a fill hose included. If using a 1-gallon bottle, be sure to use a clean funnel for your fill. DEF is sensitive to contamination and a dirty funnel can cause problems. SOURCES: Domestic Diesel 909.664.7679 DomesticiDieselShop.com Total 0 Shares Share 0 Tweet 0 Pin it 0 Share 0
