Up next The 1955 Mysterious Massey-Harris 33D Published on July 25, 2022 Author Jason Sands Share article Facebook 0 Twitter 0 Mail 0 Edge Products Pulsar 6.6L Duramax Power Tuner A 50-State-Legal Tuning with over 136 horsepower gain at the Wheels! Around a decade ago it seemed like it was the wild West with diesel performance–crazy power gains, smoke at the touch of a button, and easily defeatable emissions systems. Fast forward to 2022 and all of that has changed with newer trucks. They have computers that are not easily fooled or modified, and even if they could be, the EPA has been handing out millions in fines and cracking down hard on literally everyone–manufacturers, shops, and even end users. We wondered, where does this leave diesel performance? If the Edge Pulsar looks like a computer, that’s because it is! Also in addition to adding power, it can adjust the speed limiter and low tire pressure settings offer correction for different gear rations, can clear DTC codes, and offers high idle and manual regens. It also will back down the power if it sees a transmission slip, or excessive EGT (neither of which we saw). Well as it turns out, things aren’t so bad because where there’s a will there’s a way. For one, the manufacturers have responded with more powerful trucks right off the factory lot. GM was not lost in the mix in this, and in 2017 they introduced the L5P Duramax, the most powerful 6.6L to date. The engine retained the same basic architecture, yet was now rated at 445hp and 910 lb-ft from the showroom floor. Even with new diesels getting heavier and heavier, that’s still some healthy horsepower. Since both Pulsars were already installed we didn’t get to follow along on the installation process, but Edge has a very good YouTube video detailing how the Pulsar is attached to the factory computer. The Edge computer is roughly the same size as the factory ECM and plugs directly into its ports, making it a true “piggyback” ECM. Like everything though, the OEMs still play it safe on a number of aspects, and there was room in the aftermarket to grow. Enter the Pulsar, from Edge Products Inc. Edge, has been one of the leaders in 50-state emissions legal products for years, and has spent millions of dollars ensuring they can roll out a polished and well-thought-out product. The big headline of course is that Edge can add “up to” 136hp and 293lb-ft of torque to a 2017-2021 L5P GM Duramax. While the “up to” part might seem misleading, it’s really not. Trucks can vary slightly by year, might have added tires and wheels, be run at elevations, and who knows what else. So power can actually vary a good amount from truck to truck.Subscribe Our Weekly Newsletter Dyno Testing Since we know how you guys are, we were most concerned with “bragging rights” numbers–the difference in peak power to peak power. For this test, we had two different trucks. One was a completely stock 2021 with a Pulsar, the other was 2020 that had a Pulsar and an air intake. In both cases, the trucks rolled on factory exhaust and wheels and tires. Truck #1: 2020 GMC 2500HD Our first truck was a 2020 GMC, that only had the Pulsar and an aftermarket intake. Based on previous experience, we expected it to hit around 400 hp to the tires stock, and we were very close, as level “0” put down a 413-hp reading. After the baseline, changing power levels was as easy as a simple flick of a couple of switches on the dash. As levels went up (there are 5) so did the power. Once level 5 was finally reached, the truck put down an impressive 514rwhp–that’s 110-hp more than stock! But wait, we weren’t done yet. The truck was cooled down, big fans were turned on, and the hood was popped. The result was an impressive but puzzling 548rwhp! That was followed by a backup run of 546rwhp. This almost exactly matched Edge’s claims, as the truck picked up a whopping 135-hp over stock. Our only guess is that the popped hood allowed for a lot more fresh air, indicating the GMs probably make a bit more power rolling down the road than sitting on a dyno. Our testing would be performed on a large roller Dynojet 248C, which has been one of the industries leading dynos for decades. The elevation of Riverdale, CA is around 200 feet, so we’d basically be performing the tests at sea level. For the ultimate in stealth, tunes can be changed just by a few switch flicks on the dash. In this case, the 40-mph reading indicates the tune is on Level 4. Truck # 2: 2021 GMC 2500HD Denali Our second test truck was a year newer, and pretty much bone stock except for the Edge Pulsar. With everything on “0”, it was pretty much in line with 2020, making a couple of hp less and coming in at 394rwhp. Just like before, we ran the test going up with hotter tunes in succession, all the way up to Level 5. Just like before things started ramping up immediately once we hit Level 1 with 424 hp, Level 2 was 440hp, and Level 3 was 455 hp. So far so good. Level 4 was a big jump with 490hp, and finally, Level 5 cranked out 522rwhp–that’s 128 hp more than stock! On the dyno, our first 2020 GMC test subject cranked out power readings from 413rwhp (stock) to a whopping 548rwhp on Level 5. Testing Thoughts After our test, we have to say that Edge is pretty much spot-on in their maximum horsepower estimates, with maybe a 10-hp leeway here or there. As always we were impressed by virtually zero smoke, and their 50-State compliance badge was definitely well deserved. If you look back 15 years ago, making 550rwhp with a Duramax would have meant injectors, a turbo, transmission, lift pump, and tuning at the very least, and probably a modified or second CP3 pump. The fact that you can make the same power today with just a tune is awesome, and a testament to the advancement of modern performance. Is diesel performance dead? Heck no, it’s just coming into its own. The 6.6L Duramax engine was bone stock in both the 2020 and 2021 trucks, but there was still some untapped power left inside. The Dynojet was smokin’ as we made run after run. Power increased at every setting, but Level 4 and Level 5 are where things really got serious. While peak power is fun, the Pulsar was able to add horsepower throughout the entire rpm range, giving credence to its whopping 293 lb-ft claim. We had the rare opportunity to test a product on two different trucks, so we went for it. 2021 we tested was very similar to 2020, other than having the factory intake. The GMC had the same Pulsar that the other 2020 pickup did, and we were expecting similar power numbers. Our 2021 test vehicle didn’t make quite the power 2020 did, but it was still able to break the 500-hp mark with a 522-hp pull. SOURCE Brown’s Diesel brownsdiesel.com 559.867.1111 Edge Products edgeproducts.com 888.360.3343 Total 0 Shares Share 0 Tweet 0 Pin it 0 Share 0
